Single Phase Smart Meter With LCD Display
●DIN35mm standard rail type installation, LCD display
●With active energy metering and voltage, current, power, power factor and other electrical parameter measurement functions
●With RS485 communication interface,support modbus-RTU communication protocol
- Product Introduction
SPECIFICATIONS
|
Measurement ● Connection type: 1P2W ● Accuracy: Class 1.0 for active |
LED Indication ● Pulse Indication |
|
Voltage ● Nominal voltage (Un): 220V, 230V,240V ● Operating range: 0.85Un ~ 1.15Un ● Power consumption: ≤1W,8VA |
Measured Values ● Total kWh ● Instantaneous kW,Vrms,Irms, frequency,power factor |
|
Current ● 5(80)A |
Communications(Optional) ● RS485 ● Protocol:Modbus-RTU |
|
Frequency ● 50Hz or 60Hz |
Environmental ● Working temperature range:-10℃ to +45℃ ● Limited temperature range:-25℃ to +75℃ ●Relative humidity(Annually average): ≤ 75% |
|
LCD Display ● 6 character of 7 segment display ● Digital size: 5.3mm x 2.8mm |
Dimensions ● Dimensions: 98mm x 65mm x 36mm |
LCD INDICATION
Units : mm
METER DIMENSIONS
Units: mm
